High Speed Precision Mechanical Metal Lathe Machine For Steel

FOB Reference Price:Get Latest Price
$15,833.00 - $34,166.00 / Set | 1 Set/Sets (Min. Order)
Max. Swing Diameter (mm):
1000mm
Spindle bore:
440
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 30 Negotiable
Customization:
Customized packaging (Min. Order: 1 Sets)
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Range of Spindle Speed(r.p.m):
10 - 230 r.p.m
Machining Capacity:
Medium duty
Spindle Bore(mm):
440 m'm
Width of bed (mm):
755
Max. Turned Length (mm):
4850 mm
Type:
HORIZONTAL
Spindle Motor Power(kW):
22
Year:
2018
Place of Origin:
Shandong, China
Brand Name:
SHANDONG
Model Number:
Q1343A
Voltage:
220/380
Dimension(L*W*H):
5800/2250/2250
Certification:
CE ISO
Weight (KG):
13000 KG
Warranty:
1 YEAR
After-sales Service Provided:
Online support, Video technical support, Free spare parts, Field installation, commissioning and training, Field maintenance and repair service
Key Selling Points:
long service life
Applicable Industries:
Manufacturing Plant, Construction works
After Warranty Service:
Video technical support, Online support, Spare parts, Field maintenance and repair service
Local Service Location:
canada, turkey, United States, GERMANY, VIET NAM, brazil, peru, SAUDI ARABIA, indonesia, pakistan, Mexico, RUSSIA, malaysia, Australia, kenya, argentina, South Korea, UAE, Romania, south africa, KAZAKHSTAN, UKRAINE, kyrgyzstan, NIGERIA, uzbekistan, Tajikistan
Showroom Location:
france, GERMANY, VIET NAM, philippines, peru, SAUDI ARABIA, pakistan, RUSSIA, argentina, South Korea, UAE, Colombia, algeria, Sri Lanka, Romania, south africa, KAZAKHSTAN, UKRAINE, kyrgyzstan, NIGERIA, uzbekistan
Name:
High Speed Precision Mechanical Metal Lathe Machine For Steel
Product type:
Conventional Horizontal Large Diameter Universal Lathe Machine
Max. workpiece length:
5000mm
Guideway width:
755mm
Max.swing over carriage:
610mm
Hole through spindle:
440mm
Rapid speeds of X/Z axis:
3000/6000mm
Max. length of turning:
4850mm
Max.load of lathe bed:
6000KG
Precision:
Precision Double chucks lathe
CNC or Not:
normal
Automatic Grade:
manual
Max. Swing Diameter (mm):
1000 mm
Max. Length of Workpiece (mm):
5000 mm
Supply Ability
Supply Ability:
500 Set/Sets per Year High Speed Precision Mechanical Metal Lathe Machine For Steel
Packaging & Delivery
Packaging Details
IRON CASE OR REQUEST
High Speed Precision Mechanical Metal Lathe Machine For Steel
Port
QINGDAO
Picture Example:
package-img
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 30 To be negotiated
Video Description

High Speed Precision Mechanical Metal Lathe Machine For Steel

Photos of Mahine
High Speed Precision Mechanical Metal Lathe Machine For Steel

Main Techinical specifications

Unit

Q1313A

Q1320A

Q1323A

Q1327A

Q1335A

Q1343A

Swing over bed

mm



630

800

1000

Swing over carriage

340

540

610

Tube outside diameter

30-127

50-196

50-220

100-275

100-350

270-430

Max length of workpiece

1500  3000  5000

Max length of turning

1350  2850  4850

Span of guideway

550

755

Max load of Lathe bed

KG

3000

5000

Quenching hardness



≤HRC55

Spindle bore(dia)

mm

130

200

225

280

355

440

Mode of spindle speed



2

3

2

3



Range of spindle speed

r/min

20-800

20-450

10-300

10-230

Power of main motor



11



15

22

Motor frequency converter

Size of chuck

4000/3 jaw

500/3 jaw

800/4 jaw

1000/3 jaw

Transverse feed range

r/min

0.05~0.75/32

Longitudinal feed range

0.1-1.5/32

Screw pitch of leadscrew

mm

12

Rapid traverse speed

mm/min

4000

Taper hole of tailstock quill



Morse 5

Morse 6

I Max taper machining length

mm

700

Length ( L)

3700/5200/7200

4400(1.5m)

5800(1.5m)

Width(W/H)

1700/1600

1850/1680

1900/1700

2080/1950

2200/2170

2250/2250

Machine weight (1500mm)

KG

4700

5000

5200

7500

12500

13000

Q13 series pipe thread lathe is specially developed by our company for the processing of AP pipe threads in the oilfield industry.The machine tool has a large spindle through-hole and a double chuck clamping structure on the front and back.It is suitable for all kinds of long pipe cylindrical threads, tapered threads and Turning of special threads.At the same time, it also has all the functions of ordinary CNC lathes. It can replace ordinary CNC lathes to process complex shaped shafts, sleeves, disks and other parts, such as turning inner and outer cylindrical surfaces, conical surfaces, arc surfaces, end faces , Grooving, chamfering, threading, etc., strong process adaptability, high processing efficiency, uniform product. This machine tool has a novel appearance, simple operation, mature structure and stable performance, and is widely used in petroleum, natural gas, chemical, hydropower, and geological exploration departments.
Structural features of pipe thread lathe:
1. The bed is made of high standard cast iron (HT300) secondary molding and casting. After secondary aging treatment, it has strong stability, good rigidity and strong seismic resistance.
2. The guide rail surface is subjected to high-frequency quenching (Rockwell hardness can reach HRC55 or higher). The imported guide rail grinder is used for precision grinding to ensure long life, high accuracy and good retention of the guide rail surface.
3.3 The headstock box of the 3 spindle is completed by one-time molding of the imported horizontal boring and milling machining center. The spindle has high concentricity, strong structural rigidity, and can adapt to heavy cutting. Stable, both recutting and finishing.
4. Automatic forced circulation lubrication makes the transmission system run flexibly and can effectively cool down. Each sliding rail pair is coated with TSF soft belt, which greatly reduces the friction coefficient and improves the service life of the rail.
5. Equipped with a four-station electric tool post as standard, quick and easy tool change.
Checkout Equipment

Engine Lathe Specification heavy common lathe and metal lathe machine
SANZHENG Pipe threading lathe advantages:
1. We research and develop Pipe threading lathe for more than 50 years, and our company was restructured in the year 2002 . More than 200 staff ,9 professional engineers ,cover an area of 120,000 square meters.
2.CNC pipe threading lathe is a special model of CNC turning lathe ,mainly used in oil and gas field, machinery manufacturing, geological exploration, thread repair function and so on.
3. Customized service, we can make the pipe threading lathe according to clients’ requirements.
4. We have our own casting workshop, guarantee good quality of the machine.
5. A big production capacity, always have machines in store, though so many orders we can also guarantee delivery time.
6. We have exported to Dubai , Malaysia,the USA ,Russia, Iran etc.
7. We make OEM for Knuth Germany about 8 year ,no quality problem , the orders are added every year.

Related Products



Company Profile

Certificate



SANZHENG Pipe threading lathe after-sales service:
First-class manufacturing equipment, first-class quality guarantee.
The pipe threading lathe has won the unanimous trust and praise from domestic and foreign customers for its high quality product and timely after-sales service! "To develop by quality, to survive in good faith” is the constant business philosophy
Design With Passion:
Certified with European CE and China official design & ISO9001 Quality Management System Certification, Sanzheng experienced internal engineers are standing by to build customized proposal to realize customers’ target in terms of productivity, flexibility and investment pay back.
Technology With Innovation :
Sanzheng is continuously growing to affirm innovative solutions and managing to foresee the emergent demands of the markets, Which has made Sanzheng be able to guarantee a high return and full capacity utilization of your Pipe threading machine
Quality With Consideration:
Sanzheng insists on complete quality control from raw material processing to machine parts assembly then to whole machine working system.
The customers service is not only involves in the process of selling and the short installation, but also accompanies your complete production enduringly.
First-class manufacturing equipment, first-class quality guarantee.
"SANZHENG Pipe Threading Lathe Machine is professional pipe threading lathe manufacturers and suppliers in China, providing bulk products for sale. Welcome to wholesale high quality cnc pipe threading lathe at cheap price from our factory.
