Wholesale Siemens 808D or FANUC Control System CNC Mini Metal Lathe Machines Cost Price With Automation

FOB Reference Price:Get Latest Price
$20,833.00 - $55,833.00 / Set | 1 Set/Sets (Min. Order)
Spindle bore:
105
Max. Swing Diameter (mm):
800mm
Shipping:
Support Sea freight
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 30 Negotiable
Customization:
Customized packaging (Min. Order: 1 Sets)
Report Suspicious Activity
Overview
Quick Details
Type:
Horizontal
Structure:
Flat Bed Lathe
Condition:
New
Year:
2018
Max. Spindle Speed (r.p.m):
3000 r.p.m
Machining Capacity:
Heavy Duty
Max. Weight of Workpiece(kg):
3000
Width of bed (mm):
550 mm
Spindle Motor Power(kW):
11
No. of Spindles:
Single
Max. Turned Length (mm):
2800
Number of Axes:
3
Travel (X Axis)(mm):
3000 mm
Travel (Z Axis)(mm):
2800 mm
Positioning Accuracy (mm):
0.001
Repeatability (X/Y/Z) (mm):
0.002
Place of Origin:
Shandong, China
Dimension(L*W*H):
3830*1750*1620mm
Brand Name:
Sanzheng
Model Number:
CK6280G
Voltage:
380V
Certification:
CE&ISO
CNC Control System:
FANUC
Toolpost Brand:
Hydex
Tool Post Stations:
12
Weight (KG):
2550
Warranty:
1 YEAR
After-sales Service Provided:
Online support, Video technical support, Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Engineers available to service machinery overseas
After Warranty Service:
Video technical support, Online support, Spare parts, Field maintenance and repair service
Applicable Industries:
Machinery Repair Shops, Manufacturing Plant, Energy & Mining
Key Selling Points:
High-accuracy
Local Service Location:
Canada, United Kingdom, France, Germany, Saudi Arabia, Russia, Malaysia, Australia, Kenya, Argentina, South Korea, Chile, UAE, Colombia, Algeria, Sri Lanka, Romania, Bangladesh, South Africa, Kazakhstan, Ukraine, Kyrgyzstan, Nigeria, Uzbekistan, Tajikistan
Showroom Location:
United Kingdom, France, Germany, Saudi Arabia, Russia, Argentina, South Korea, UAE, Colombia, Algeria, Sri Lanka, Romania, Bangladesh, South Africa, Kazakhstan, Ukraine, Kyrgyzstan, Nigeria, Uzbekistan, Tajikistan, Malaysia, Australia
CNC or Not:
CNC
Automatic Grade:
Automatic
Max. swing over bed:
800mm
Max. swing over carriage:
550mm
Max. swing in gap:
1000mm
Hole through spindle:
105mm
Max. workpiece length:
1500mm
Name:
Wholesale Siemens 808D or FANUC Control System CNC Mini Metal Lathe
Max. Swing Diameter:
800mm
Spindle Bore(mm):
105 m'm
Max. Swing Diameter (mm):
800 mm
Max. Length of Workpiece (mm):
3000 mm
Supply Ability
Supply Ability:
20 Set/Sets per Month FANUC Control System CNC Mini Metal Lathe Machines
Packaging & Delivery
Packaging Details
wooden case
Wholesale Siemens 808D or FANUC Control System CNC Mini Metal Lathe Machines Cost Price With Automation
Port
Qingdao
Picture Example:
package-img
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 30 To be negotiated
Video Description

CK6280G Cnc Mini Lathe

Wholesale Siemens 808D or FANUC Control System CNC Mini Metal Lathe Machines Cost Price With Automation



Advantages

Application:

The application fields of Pipe Thread Lathe machine are the Processing and repairs of drill pipe, drill collar, joint, kelly bar and sleeve of Oil sector, Metallurgic Industry, Geological Prospecting, Chemical Industry & Hydropower.



Advantage:

We use electric furnace smelting, resin sand molding casting technology,avoid sand holes, stoma casting internal defect effectively, all the accessories are assayed by imported spectrum analyzer, it assures the quality of the casting . The casting had been through second thermal aging treatment with good stability.

The bed of floor type is the whole structure. The rigidity and width of guide way on the bed of lathe is good enough. The guide way is through high-frequency quenching, the slide guide way joint SD compound soft belt. to make more wear-resisting and lower friction factor. The lead screw is the whole structure (not butt). The saddle is wider and thicker than before, the machine is running more stable. And the cutting ability is better.

The 3 boxes of lathe were processed by Taiwan’s CNC boring and milling machine center. The other tools are processed by CNC lathe and machine center to ensure the precision of the box and tools.

First step of the accuracy test of the equipment is testing the repeat accuracy of X and Y axis with Renishaw laser interometer imported from Britain. After that, inspecting and accepting the whole equipment based on the enterprise standards, guarantee the accuracy of the machine tool.

Photos of Mahine



Main Parameters



Model and specifications

CK6163G

CK6263G

CK6180G

CK6280G

Max. swing over bed

630mm

800mm

Max. swing in gap



800mm



1000mm

Available length in gap



300mm



300mm

Max. swing over carriage

350mm

550mm

Max. processing length

1500/3000mm

The actual machining length

1350/2850mm

Guide-way width

550mm

Range of spindle speed changes

17-1000  r/min

Number of spindle speed changes

Hydraulic 4 stepless shift gears

Hole through spindle

Φ105mm

Taper hole of spindle

Mefric 120(1:20)

Chuck connection form

K11 Φ325(Standard)

Power of main motor

11KW

X axis max. travel

500mm

Quick traverse speed

6m/min

Minimum input unit

0.001

Repeated positioning accuracy

±0.003

Tool post style

Vertical4(Standard)

Knife rest translocation time(S)

2.4s

Processing work-piece accuracy

IT7

Processing work-piece surface roughness

Ra1.6



Checkout Equipment





Storage





Company Profile





FAQ





FAQ
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 10-15 days if the goods are in stock. or it is 30-40 days after receiving the payment in advance.
Q: What is you minimum order quantity and warranty?
A: MOQ is one set, and warranty is one year.
Q: What is your terms of payment?
A: The payment way is general Trade Assurance on Alibaba and T/T or L/C.
Q: Do you have CE or any other certificate?
A: We have certificates, such as CE, ISO, The Product Patent Certificate, Appearance Design Patent Certificate etc.
Q: What will you do if the machine cannot work during the warranty period?
A: 1. During the warranty period, because of product quality problems, the company is responsible for free maintenance,  if need to change parts, we be responsible for free replacement
     2. If the machine problem is not belonging to our machine quality problems, when the buyer needs us send engineers  to give repairing service, we charge the appropriate cost.
Q: Can you send the technical personnel to our company and direct our workers for free?
A:   When the machine arrive the buyer's installation site, we timely send mechanical and electrical engineers to install according to the buyer's schedule, the buyer undertakes accommodation of personnel abroad in the process of installation, and the seller will cooperate with the buyer to deal with visa and installation preparation before going abroad.
Any More ,Please contact  or send inquiry to us !
